BPED Series
Manufacturer: Pulse Electronics
Beta
⌘K
POWER INDUCTORS - SMD CHILISIN POWER - INDUCTOR (IND) HIGHT CURRENT TYPE
| Part | Package / Case | DC Resistance (DCR) | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Inductance | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Tolerance | Inductance Frequency - Test | Shielding | Current - Saturation (Isat) | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | Nonstandard | 1.1 mOhm | -40 C | 155 C | 33 A | 80 nH | 0.394 in | 10 mm | 3.8 mm | 0.15 " | 2.4 mm | 0.094 in | 20 % | 100 kHz | Shielded | 80 A | Surface Mount |
