392-076 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Termination | Color | Contact Finish | Pitch | Pitch | Number of Positions/Bay/Row [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Card Type | Gender | Mounting Type | Number of Positions | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Through Hole | 76 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Wire Wrap | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Through Hole | 76 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Through Hole | 76 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder Wire Wrap | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Right Angle Through Hole | 76 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder Wire Wrap | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Right Angle Through Hole | 76 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Wire Wrap | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Through Hole | 76 | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Board Edge Straddle Mount | 76 | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Board Edge Straddle Mount | 76 | Card Extender | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Board Edge Straddle Mount | 76 | Card Extender | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Solder | Black | Gold | 0.1 " | 2.54 mm | 38 | 0.25 Ám | 10 Áin | Cantilever | Dual | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Copper Alloy | Non Specified - Dual Edge | Female | Board Edge Straddle Mount | 76 | Card Extender |
