396-005 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 5POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Color | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Contact Type | Contact Finish | Number of Positions/Bay/Row | Termination | Pitch | Pitch | Card Type | Read Out | Mounting Type | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Gender | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | 0.156 " | 3.96 mm | Copper Alloy | Cantilever | Gold | 5 | Solder Wire Wrap | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Right Angle Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | Copper Alloy | Cantilever | Gold | 5 | Solder | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | Copper Alloy | Cantilever | Gold | 5 | Solder | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | Copper Alloy | Cantilever | Gold | 5 | Solder | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | Copper Alloy | Cantilever | Gold | 5 | Solder | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | 0.128 " | 3.25 mm | Copper Alloy | Cantilever | Gold | 5 | Wire Wrap | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Side Mount Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | 0.156 " | 3.96 mm | Copper Alloy | Cantilever | Gold | 5 | Solder Wire Wrap | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Right Angle Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | 0.128 " | 3.25 mm | Copper Alloy | Cantilever | Gold | 5 | Solder | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | 0.116 " | 2.95 mm | Copper Alloy | Cantilever | Gold | 5 | Wire Wrap | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Floating Bobbin Flush Mount | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.25 Ám | 10 Áin | -40 C | 105 ░C | 5 | Black | 0.128 " | 3.25 mm | Copper Alloy | Cantilever | Gold | 5 | Solder Wire Wrap | 3.18 mm | 0.125 in | Non Specified - Single Edge | Single | Right Angle Through Hole | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Flush Mount Top Opening Unthreaded |
