AA30T Series

Catalog

AC/DC CONVERTER 5V +/-12V 30W

Part	Line Regulation	Weight	Weight	Load Regulation	Current - Output (Max)	Current - Output (Max)	Current - Output (Max)	Efficiency	Features	Mounting Type	Package / Case	Standard Number	Type	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Number of Outputs	Applications	Voltage - Output 1	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Approval Agency	Voltage - Output 3	Current - Output 2	Current - Output 1	Current - Output 3	Voltage - Output 2	Voltage - Isolation	Current - Output (Max) [Max]
Delta Electronics AA30T051212A	0.2 %	176.9 g	0.39 lb	2.5 % 4 %	3 A	600 mA	600 mA	76 %	Universal Input	Through Hole	7-DIP Module	60950-1	Enclosed	89.9 mm	3.5 "	21.7 mm	63.5 mm	2.5 "	0.85 "	3	ITE (Commercial)	5 V	70 °C	-25 °C	30 Watts	CE cUL UL
Delta Electronics AA30T121205C								76 %	DC Input Capable Universal Input	Chassis Mount			Enclosed	112 mm	4.41 "	25.6 mm	63.8 mm	2.51 "	1.01 "	3	ITE (Commercial)	12 V	70 °C	-25 °C	30 Watts	CE	5 V	250 mA	1 A	3 A	-12 V	3000 V
Delta Electronics AA30T050312C								71 %	DC Input Capable Universal Input	Chassis Mount			Enclosed	112 mm	4.41 "	25.6 mm	63.8 mm	2.51 "	1.01 "	3	ITE (Commercial)	5 V	70 °C	-25 °C	30 Watts	CE	12 V	1 A	4.5 A	250 mA	3.3 V	3000 V
Delta Electronics AA30T050312A	0.2 %	176.9 g	0.39 lb	2.5 % 4 %	1 A 4.5 A 250 mA			71 %	Universal Input	Through Hole	7-DIP Module	60950-1	Enclosed	89.9 mm	3.5 "	21.7 mm	63.5 mm	2.5 "	0.85 "	3	ITE (Commercial)	5 V	70 °C	-25 °C	30 Watts	CE cUL UL
Delta Electronics AA30T030512C								71 %	DC Input Capable Universal Input	Chassis Mount			Enclosed	112 mm	4.41 "	25.6 mm	63.8 mm	2.51 "	1.01 "	3	ITE (Commercial)	3.3 V	70 °C	-25 °C	30 Watts	CE	12 V	1.5 A	4 A	250 mA	5 V	3000 V
Delta Electronics AA30T030512A	0.2 %	176.9 g	0.39 lb	2.5 % 4 %				71 %	Universal Input	Through Hole	7-DIP Module	60950-1	Enclosed	89.9 mm	3.5 "	21.7 mm	63.5 mm	2.5 "	0.85 "	3	ITE (Commercial)	3.3 V	70 °C	-25 °C	30 Watts	CE cUL UL							1.5 A 4 A 250 mA
