Power Inductors - SMD 300nH SMT
Power Inductors - SMD 300nH SMT
| Part | Tolerance | Material - Core | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Package / Case | DC Resistance (DCR) | Inductance | Current Rating (Amps) | Shielding | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Type | Inductance Frequency - Test | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Current - Saturation (Isat) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | 10 % | Ferrite | 8 mm | 0.315 in | Nonstandard | 0.29 mOhm | 300 nH | 51 A | Unshielded | Surface Mount | 125 °C | -40 C | Drum Core Wirewound | 100 kHz | 0.37 in | 9.4 mm | 0.244 in | 6.2 mm | 27.5 A |
