XT37 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURPOSE SPDT 16A 24V
| Part | Coil Resistance | Release Time | Operate Time | Operating Temperature [Max] | Operating Temperature [Min] | Must Release Voltage | Switching Voltage [Max] | Coil Voltage | Coil Current | Load - Max Switching | Contact Material | Contact Form | Features | Contact Rating (Current) | Termination Style | Approval Agency | Must Operate Voltage | Coil Type | Mounting Type | Relay Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 1440 Ohms | 6 ms | 9 ms | 70 °C | -40 C | 2.4 VDC | 400 VAC | 24 VDC | 16.7 mA | 6400 VA | Silver Nickel (AgNi) | SPDT (1 Form C) | Diode Lighted Indicator | 16 A | Plug In | cURus VDE | 16.8 VDC | Non Latching | Socketable | General Purpose |
 TE Connectivity AMP Connectors | 8.1 kOhms | 6 ms | 9 ms | 70 °C | -40 C | 17.3 VAC | 400 VAC | 115 VAC | 16.7 mA | 6400 VA | Silver Nickel (AgNi) | SPDT (1 Form C) | Lighted Indicator | 16 A | Plug In | cURus VDE | 86.3 VAC | Non Latching | Socketable | General Purpose |
 TE Connectivity AMP Connectors | 32500 Ohms | 6 ms | 9 ms | 70 °C | -40 C | 34.5 VAC | 400 VAC | 230 VAC | 16.7 mA | 6400 VA | Silver Nickel (AgNi) | SPDT (1 Form C) | Lighted Indicator | 16 A | Plug In | cURus VDE | 172.5 VAC | Non Latching | Socketable | General Purpose |
