396-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 50POS 0.125
| Part | Termination Rows | Material - Insulation | Card Type | Number of Positions | Pitch | Pitch | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Contact Finish | Read Out | Color | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Number of Rows | Contact Material | Termination | Mounting Type | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | Gold | Single | Black | Cantilever | 0.25 Ám | 10 Áin | 50 | 1 | Copper Alloy | Solder Wire Wrap | Right Angle Through Hole | ||||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder | Through Hole | 2 | 2 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder | Through Hole | 2 | 2 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Side Opening Unthreaded | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Wire Wrap | Through Hole | 2 | 2 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder | Through Hole | 2 | 2 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder | Through Hole | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder Wire Wrap | Right Angle Through Hole | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder | Through Hole | 2 | 2 | 0.116 " | 2.95 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | Gold | Dual | Black | Cantilever | 0.25 Ám | 10 Áin | 25 | Copper Alloy | Solder | Through Hole | 2 | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | 50 | 3.18 mm | 0.125 in | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | Gold | Single | Black | Cantilever | 0.25 Ám | 10 Áin | 50 | 1 | Copper Alloy | Solder | Through Hole |
