Power Inductors - SMD 4.0uH 12A 6.0mOhms
Power Inductors - SMD 4.0uH 12A 6.0mOhms
| Part | Mounting Type | Inductance | Current Rating (Amps) | Material - Core | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Shielding | Inductance Frequency - Test | Type | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Tolerance | DC Resistance (DCR) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Eaton - Electronics Division | Surface Mount | 4 µH | 10.9 A | Ferrite | Nonstandard | 125 °C | -40 C | Unshielded | 100 kHz | Drum Core Wirewound | 0.197 in | 5 mm | 12.5 mm | 0.492 " | 12.5 mm | 0.492 " | 20 % | 7.2 mOhm |
