396-060 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 60POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Gender | Color | Features | Contact Type | Number of Positions | Mounting Type | Termination | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Contact Material | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Card Extender | Cantilever | 60 | Board Edge Straddle Mount | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 0.156 " | 3.96 mm | 3.18 mm | 0.125 in | Copper Alloy | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Cantilever | 60 | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Card Extender | Cantilever | 60 | Board Edge Straddle Mount | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Cantilever | 60 | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Copper Alloy | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Card Extender | Cantilever | 60 | Board Edge Straddle Mount | Solder Eyelet(s) | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Copper Alloy | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Cantilever | 60 | Through Hole | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Card Guides | Cantilever | 60 | Right Angle Through Hole | Solder Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Cantilever | 60 | Through Hole | Wire Wrap | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 0.116 " | 2.95 mm | 3.18 mm | 0.125 in | Copper Alloy | Floating Bobbin Flush Mount | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Cantilever | 60 | Through Hole | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 0.156 " | 3.96 mm | 3.18 mm | 0.125 in | Copper Alloy | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Female | Black | Cantilever | 60 | Through Hole | Solder | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 30 | Dual | -40 C | 105 ░C | 2 | Non Specified - Dual Edge | 0.128 " | 3.25 mm | 3.18 mm | 0.125 in | Copper Alloy |
