1N3611 Series

Catalog

DIODE GEN PURP 200V 1A DO204AL

Part	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Supplier Device Package	Technology	Voltage - Forward (Vf) (Max) @ If [Max]	Mounting Type	Current - Average Rectified (Io)	Package / Case	Current - Reverse Leakage @ Vr	Speed [Min]	Voltage - DC Reverse (Vr) (Max) [Max]	Reverse Recovery Time (trr)	Capacitance @ Vr, F	Grade	Qualification
Vishay General Semiconductor - Diodes Division 1N3611GP-M3/54	175 ░C	-65 C	DO-204AL (DO-41)	Standard	1 V	Through Hole	1 A	Axial DO-204AL DO-41	1 µA	200 mA 500 ns	200 V	2 µs	8 pF
Vishay General Semiconductor - Diodes Division 1N3611GPHE3/54	175 ░C	-65 C	DO-204AL (DO-41)	Standard	1 V	Through Hole	1 A	Axial DO-204AL DO-41	1 µA	200 mA 500 ns	200 V	2 µs	8 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division 1N3611GPHE3/73	175 ░C	-65 C	DO-204AL (DO-41)	Standard	1 V	Through Hole	1 A	Axial DO-204AL DO-41	1 µA	200 mA 500 ns	200 V	2 µs	8 pF	Automotive	AEC-Q101
Vishay General Semiconductor - Diodes Division 1N3611GP-E3/54	175 ░C	-65 C	DO-204AL (DO-41)	Standard	1 V	Through Hole	1 A	Axial DO-204AL DO-41	1 µA	200 mA 500 ns	200 V	2 µs
Vishay General Semiconductor - Diodes Division 1N3611GP-E3/73	175 ░C	-65 C	DO-204AL (DO-41)	Standard	1 V	Through Hole	1 A	Axial DO-204AL DO-41	1 µA	200 mA 500 ns	200 V	2 µs
