396-096 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 96POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Read Out | Contact Material | Card Type | Number of Rows [custom] | Contact Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Color | Mounting Type | Number of Positions/Bay/Row | Number of Positions | Termination | Contact Finish | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Right Angle Through Hole | 48 | 96 | Solder Wire Wrap | Gold | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Right Angle Through Hole | 48 | 96 | Solder Wire Wrap | Gold | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Right Angle Through Hole | 48 | 96 | Solder Wire Wrap | Gold | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Through Hole | 48 | 96 | Wire Wrap | Gold | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Board Edge Straddle Mount | 48 | 96 | Solder | Gold | Card Extender Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Through Hole | 48 | 96 | Solder | Gold | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Board Edge Straddle Mount | 48 | 96 | Solder Eyelet(s) | Gold | Card Extender | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Through Hole | 48 | 96 | Wire Wrap | Gold | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Through Hole | 48 | 96 | Wire Wrap | Gold | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Dual | Copper Alloy | Non Specified - Dual Edge | 2 | Cantilever | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | -40 C | 105 ░C | 0.25 Ám | 10 Áin | Black | Through Hole | 48 | 96 | Solder | Gold | Card Guides |
