87989 Series

Catalog

CONN RCPT 5POS 0.156 GOLD PCB

Part	Insulation Material	Contact Shape	Contact Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Operating Temperature [Max]	Operating Temperature [Min]	Style	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Number of Rows	Mounting Type	Number of Positions	Contact Finish - Mating	Termination	Insulation Color	Insulation Height	Insulation Height	Contact Length - Post [x]	Contact Length - Post [x]	Material Flammability Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Fastening Type	Contact Type	Connector Type	Number of Positions Loaded
TE Connectivity AMP Connectors 87989-5	Thermoplastic	Square	Phosphor Bronze	1.27 µm	50 µin	105 ░C	-65 ░C	Board to Board Cable	3.96 mm	0.156 in	Aluminum	1	Through Hole	5	Gold	Solder	Black	7.62 mm	0.3 in	0.112 in	2.84 mm	UL94 V-0	0.76 Ám	30 Áin	Push-Pull	Female Socket	Receptacle Bottom Entry	All
TE Connectivity AMP Connectors 87989-6	Thermoplastic	Square	Phosphor Bronze	1.27 µm	50 µin	105 ░C	-65 ░C	Board to Board Cable	3.96 mm	0.156 in	Aluminum	1	Through Hole	6	Gold	Solder	Black	7.62 mm	0.3 in	0.112 in	2.84 mm	UL94 V-0	0.76 Ám	30 Áin	Push-Pull	Female Socket	Receptacle Bottom Entry	All
TE Connectivity AMP Connectors 87989-2	Thermoplastic	Square	Phosphor Bronze	1.27 µm	50 µin	105 ░C	-65 ░C	Board to Board Cable	3.96 mm	0.156 in	Aluminum	1	Through Hole	2	Gold	Solder	Black	7.62 mm	0.3 in	0.112 in	2.84 mm	UL94 V-0	0.76 Ám	30 Áin	Push-Pull	Female Socket	Receptacle Bottom Entry	All
