har-flexicon FPH Series
Manufacturer: HARTING
Beta
⌘K
PLUGGABLE TERMINAL BLOCK, 5.08 MM, 8 POSITIONS, 30 AWG, 12 AWG, 2.5 MM², PUSH IN
| Part | Contact Material | Wire Strip Length | Insulation Height | Insulation Height | Housing Material | Material Flammability Rating | Pitch | Pitch | Positions Per Level | Color | Termination Style | Type | Wire Gauge or Range - mm² [Max] | Wire Gauge or Range - mm² [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Current - UL | Number of Positions | Plug Wire Entry | Contact Mating Finish | Number of Levels | Wire Gauge or Range - AWG [Max] | Wire Gauge or Range - AWG [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 HARTING | Copper Alloy | 10 mm | 0.587 in | 14.91 mm | Nylon Polyamide (PA) Polyphthalamide (PPA) | UL94 V-0 | 5.08 mm | 0.2 in | 8 | Green | Screwless - Spring Cage Tension Clamp | Plug Female Sockets | 2.5 mm² | 0.2 mm² | -40 C | 110 °C | Free Hanging (In-Line) | 12 A | 8 | 180 ° | Tin | 1 | 30 AWG | 12 AWG |
 HARTING | 5 mm | 0.197 in | 2 | Green | Screwless - Spring Cage Tension Clamp | Plug Female Sockets | 2.5 mm² | 0.2 mm² | -40 C | 110 °C | Free Hanging (In-Line) | 12 A | 2 | 180 ° | Tin | 1 | 30 AWG | 12 AWG |
