WIREWOUND RESISTORS - CHASSIS MOUNT 50W 6800 OHMS 5%

...

Part	Power (Watts)	Tolerance	Lead Style	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Composition	Resistance	Temperature Coefficient	Package / Case	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Coating, Housing Type	Mounting Feature	Features	Height - Seated (Max)
Ohmite HS50 6K8 J	50 W	5 %	Solder Lugs	14.8 mm	0.583 in	Wirewound	6.8 kOhms	25 ppm/°C	Axial Box	14.2 mm	0.559 in	1.933 in	49.1 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS250 2R7 F	250 W	1 %	M6 Threaded		1.646 in	Wirewound	2.7 Ohms	100 ppm/°C 100 ppm/°C	Axial Box	45.5 mm 72.5 mm	1.791 in 2.854 in	4.319 in	109.7 mm	Aluminum	Flanges	Pulse Withstanding	41.8 mm
Ohmite HS75 10R J	75 W	5 %	Solder Lugs	24.1 mm	0.949 in	Wirewound	10 Ohms	100 ppm/°C	Axial Box	27.3 mm	1.075 in	1.917 in	48.7 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS150 47R F	150 W	1 %	Solder Lugs	24.1 mm	0.949 in	Wirewound	47 Ohms	100 ppm/°C	Axial Box	27.3 mm	1.075 in	3.846 in	97.7 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS25 3K3 J	25 W	5 %	Solder Lugs	14.8 mm	0.583 in	Wirewound	3300 Ohms	25 ppm/°C	Axial Box	14.2 mm	0.559 in	1.075 "	27.3 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS50 6K8 J	50 W	5 %	Solder Lugs	14.8 mm	0.583 in	Wirewound	6.8 kOhms	25 ppm/°C	Axial Box	28 mm	1.102 "	1.933 in	49.1 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS100 470R J	100 W	5 %	Solder Lugs	24.1 mm	0.949 in	Wirewound	470 Ohms	100 ppm/°C	Axial Box	27.3 mm 47.5 mm	1.075 in 1.87 "	2.567 "	65.2 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS250 10R F	250 W	1 %	M6 Threaded		1.646 in	Wirewound	10 Ohms	100 ppm/°C	Axial Box	45.5 mm	1.791 in	4.319 in	109.7 mm	Aluminum	Flanges	Pulse Withstanding	41.8 mm
Ohmite HS10 82R F	10 W	1 %	Solder Lugs	8.8 mm	0.346 "	Wirewound	82 Ohms	100 ppm/°C	Axial Box	8.5 mm	0.335 in	0.626 in	15.9 mm	Aluminum	Flanges	Pulse Withstanding
Ohmite HS50 6R F	50 W	1 %	Solder Lugs	14.8 mm	0.583 in	Wirewound	6 Ohms	100 ppm/°C	Axial Box	14.2 mm	0.559 in	1.933 in	49.1 mm	Aluminum	Flanges	Pulse Withstanding
