10TVE Series

Catalog

CAP TANT POLYMER 68UF 10VDC D2E CASE 20%( 7.3 X 4.3 X 1.8MM) INWARD L SMD 0.025 OHM 125°C T/R

Part	Package / Case	Mounting Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Capacitance	Features	Voltage - Rated	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Lifetime @ Temp.	ESR (Equivalent Series Resistance)	Manufacturer Size Code	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Panasonic Electronic Components 10TVE68M	2917 (7343 Metric)	Surface Mount	0.169 "	7.3 mm	0.287 "	4.3 mm	68 µF	General Purpose	10 V	20 %	-55 C	125 °C	1000 Hrs	25 mOhm	D2E	0.079 in	2 mm	Molded
Panasonic Electronic Components 10TVE150ML	2917 (7343 Metric)	Surface Mount	0.169 "	7.3 mm	0.287 "	4.3 mm	150 µF	General Purpose	10 V	20 %	-55 C	125 °C	1000 Hrs	25 mOhm	D3L			Molded	0.118 "	3 mm
