BP5277 Series

Catalog

DC DC CONVERTER 5V 2.5W

Part	Efficiency	Package / Case	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Applications	Mounting Type	Voltage - Input (Min) [Min]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Voltage - Output 1	Type	Power (Watts)
Rohm Semiconductor BP5277-50	83 %	3-SIP Module	1	85 °C	-30 ░C	32 V	500 mA	ITE (Commercial)	Through Hole	8 V	6.2 mm	1.04 in	0.24 in	26.4 mm	0.64 "	16.3 mm	5 V	Linear Regulator Replacement
Rohm Semiconductor BP5277-12	90 %	3-SIP Module	1	85 °C	-30 ░C	32 V	500 mA	ITE (Commercial)	Through Hole	15 V	6.2 mm	1.04 in	0.24 in	26.4 mm	0.64 "	16.3 mm	12 V	Linear Regulator Replacement	6 W
Rohm Semiconductor BP5277-33	76 %	3-SIP Module	1	85 °C	-30 ░C	32 V	500 mA	ITE (Commercial)	Through Hole	8 V	6.2 mm	1.04 in	0.24 in	26.4 mm	0.64 "	16.3 mm	3.3 V	Linear Regulator Replacement	1.65 W
Rohm Semiconductor BP5277-90	88 %	3-SIP Module	1	85 °C	-30 ░C	32 V	500 mA	ITE (Commercial)	Through Hole	12 V	6.2 mm	1.04 in	0.24 in	26.4 mm	0.64 "	16.3 mm	9 V	Linear Regulator Replacement	4.5 W
Rohm Semiconductor BP5277-15	93 %	3-SIP Module	1	85 °C	-30 ░C	32 V	500 mA	ITE (Commercial)	Through Hole	19 V	6.2 mm	1.04 in	0.24 in	26.4 mm	0.64 "	16.3 mm	15 V	Linear Regulator Replacement	7.5 W
