rb2 Series
Manufacturer: E-Switch
Beta
⌘K
ROCKER; DPST; POS: 2; OFF-ON; 8A/250VAC; TRANSPARENT; RB2; -20÷85°C
| Part | Illumination Type, Color | Circuit | Voltage Rating - AC | Actuator Marking | Current Rating (Amps) | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Actuator Type | Termination Style | Color - Actuator/Cap | Mounting Type | Switch Function | Illumination Voltage (Nominal) | Ingress Protection | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 E-Switch | Blue Neon | DPST | 125 V | No Marking | 16 A | 30 mm | 22 mm | Flat - Illuminated | Quick Connect - 0.250" (6.3mm) | Blue | Panel Mount Snap-In | On-Off | 250 VAC | ||
 E-Switch | DPST | 125 V | O - | 20 A | 30 mm | 22 mm | Concave (Curved) | Quick Connect - 0.250" (6.3mm) | White | Panel Mount Snap-In | On-Off | IP54 - Dust Protected Water Resistant | |||
 E-Switch | DPDT | 125 V | No Marking | 16 A | 30 mm | 22 mm | Concave (Curved) | Quick Connect - 0.250" (6.3mm) | Black | Panel Mount Snap-In | On-Off-On | 10000 Cycles | |||
 E-Switch | Incandescent Red | DPST | 125 V | O - | 16 A | 30 mm | 22 mm | Concave (Curved) - Illuminated | Quick Connect - 0.250" (6.3mm) | Red | Panel Mount Snap-In | On-Off | 12 VDC | 10000 Cycles | |
 E-Switch | DPDT | 125 V | No Marking | 16 A | 30 mm | 22 mm | Concave (Curved) | Quick Connect - 0.250" (6.3mm) | Black | Panel Mount Snap-In | Mom-Off-Mom | 10000 Cycles | |||
E-Switch | DPDT | 125 V | No Marking | 20 A | 30 mm | 22 mm | Concave (Curved) | Quick Connect - 0.250" (6.3mm) | Black | Panel Mount Snap-In | On-On | ||||
 E-Switch | DPST | 125 V | O - | 16 A | 30 mm | 22 mm | Concave (Curved) | Quick Connect | Black | Panel Mount Snap-In | On-Off | ||||
 E-Switch | Neon Amber | DPST | 125 V | Thermal Laminating Symbol | 16 A | 30 mm | 22 mm | Concave (Curved) - Illuminated | Quick Connect | Black | Panel Mount Snap-In | On-Off | 125 VAC |
