G6CK-211 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
RELAY GEN PURPOSE DPST 8A 6V
| Part | Release Time | Coil Current | Mounting Type | Seal Rating | Contact Material | Coil Type | Contact Rating (Current) | Relay Type | Contact Form | Switching Voltage | Operate Time | Termination Style | Must Operate Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Coil Resistance | Approval Agency | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 10 ms | 46.7 mA | Through Hole | Sealed - Flux Protection | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 4.2 VDC | 70 °C | -25 °C | 129 Ohms | CSA TUV UR VDE | |
Omron Electronics Inc-EMC Div | 10 ms | 93.3 mA | Through Hole | Sealed - Flux Protection | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 2.1 VDC | 70 °C | -25 °C | 32 Ohms | CSA TUV UR VDE | |
 Omron Electronics Inc-EMC Div | 10 ms | 11.7 mA | Through Hole | Sealed - Fully | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 16.8 VDC | 70 °C | -25 °C | 2 kOhms | CSA TUV UR VDE | 24 VDC |
Omron Electronics Inc-EMC Div | 10 ms | 46.7 mA | Through Hole | Sealed - Fully | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 4.2 VDC | 70 °C | -25 °C | 129 Ohms | CSA TUV UR VDE | |
Omron Electronics Inc-EMC Div | 10 ms | 23.3 mA | Through Hole | Sealed - Flux Protection | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 8.4 VDC | 70 °C | -25 °C | 515 Ohms | CSA TUV UR VDE | 12 VDC |
Omron Electronics Inc-EMC Div | 10 ms | 56 mA | Through Hole | Sealed - Flux Protection | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 3.5 VDC | 70 °C | -25 °C | 89.2 Ohms | CSA TUV UR VDE | 5 VDC |
 Omron Electronics Inc-EMC Div | 10 ms | 23.3 mA | Through Hole | Sealed - Fully | Cadmium Free Silver Alloy | Latching Dual Coil | 8 A | General Purpose | DPST-NO/NC | 125 VDC 380 VAC | 10 ms | PC Pin | 8.4 VDC | 70 °C | -25 °C | 515 Ohms | CSA TUV UR VDE | 12 VDC |
