V7-1B1 Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
MICROSWITCH, MINIATURE, SHORT LEVER, SPDT, QUICK CONNECT, 11 A, 250 VDC
| Part | Mounting Type | Pretravel | Pretravel | Switch Function | Voltage Rating - DC | Operating Force | Current Rating (Amps) | Actuator Type | Overtravel [custom] | Overtravel [custom] | Release Force | Operating Temperature [Max] | Operating Temperature [Min] | Differential Travel | Differential Travel | Mechanical Life | Voltage Rating - AC | Circuit | Termination Style | Electrical Life | Operating Position | Operating Position | Features | Differential Travel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | Chassis Mount | 0.12 in | 3 mm | On-Mom | 125 VDC | 82 gf | 11 A 500 mA | Lever Straight | 0.068 " | 1.73 mm | 8 gf | 85 °C | -40 C | 0.7 mm | 0.027 in | 10000000 Cycles | 125 V | SPDT | Quick Connect | 100000 Cycles | 15.3 mm | 0.602 in | ||
 Honeywell Sensing and Productivity Solutions | Chassis Mount | 0.236 " | 6 mm | On-Mom | 125 VDC | 50 gf | 11 A 500 mA | Lever Straight | 0.115 " | 2.9 mm | 4 gf | 85 °C | -40 C | 0.05 in | 10000000 Cycles | 125 V | SPDT | Quick Connect | 100000 Cycles | 15.5 mm | 0.61 in | Actuator Seal Boot | 1.3 mm | |
 Honeywell Sensing and Productivity Solutions | ||||||||||||||||||||||||
 Honeywell Sensing and Productivity Solutions | Chassis Mount | 0.236 " | 6 mm | On-Mom | 125 VDC | 50 gf | 11 A 500 mA | Lever Straight | 0.115 " | 2.9 mm | 4 gf | 85 °C | -40 C | 0.05 in | 10000000 Cycles | 125 V | SPDT | Quick Connect | 100000 Cycles | 15.3 mm | 0.602 in | 1.3 mm |
