ALO30F Series
Manufacturer: ARTESYN / Advanced Energy
Beta
⌘K
DC DC CONVERTER 3.3V 120W
| Part | Applications | Voltage - Input (Max) [Max] | Efficiency | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output (Max) [Max] | Voltage - Input (Min) [Min] | Package / Case | Mounting Type | Number of Outputs | Features | Voltage - Isolation | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Type | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ARTESYN / Advanced Energy | ITE (Commercial) | 75 V | 91 % | 120 W | 85 °C | -40 C | 30 A | 36 V | 8-SMD Module 1/8 Brick | Surface Mount | 1 | OCP OTP OVP Remote On/Off UVLO | 1.5 kV | 0.31 " | 7.9 mm | 2.3 in | 22.9 mm | 0.9 in | 58.4 mm | Isolated Module | 3.3 V |
 ARTESYN / Advanced Energy | ITE (Commercial) | 75 V | 91 % | 120 W | 85 °C | -40 C | 30 A | 36 V | 8-DIP Module 1/8 Brick | Through Hole | 1 | OCP OTP OVP Remote On/Off UVLO | 1.5 kV | 0.32 " | 8.1 mm | 2.3 in | 22.9 mm | 0.9 in | 58.4 mm | Isolated Module | 3.3 V |
