357-021 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
...
| Part | Termination | Contact Type | Flange Feature | Number of Positions | Contact Material | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Material - Insulation | Card Type | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Color | Number of Rows | Gender | Contact Finish | Pitch [x] | Pitch [x] | Mounting Type | Termination Rows | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Solder | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 42 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Dual Edge | Dual | -40 °C | 105 ░C | Black | 2 | Female | Tin | 0.156 in | 3.96 mm | Through Hole | 1 | |||||
 EDAC Inc. | Solder Eyelet(s) | Semi Bellows | Flush Mount Top Opening Unthreaded | 42 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Dual Edge | Dual | -40 °C | 105 ░C | Black | 2 | Female | Gold | 0.156 in | 3.96 mm | Surface Mount | 1 | 3.96 mm | 0.156 in | 10 Áin | 0.25 Ám | |
 EDAC Inc. | Solder | Semi Bellows | Floating Bobbin Flush Mount | 42 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Dual Edge | Dual | -40 °C | 105 ░C | Black | 2 | Female | Tin | 0.156 in | 3.96 mm | Through Hole | 1 | 2.95 mm | 0.116 in | |||
 EDAC Inc. | Wire Wrap | Semi Bellows | Flush Mount Top Opening Unthreaded | 42 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Dual Edge | Dual | -40 °C | 105 ░C | Black | 2 | Female | Gold | 0.156 in | 3.96 mm | Through Hole | 1 | 3.25 mm | 0.128 " | 10 Áin | 0.25 Ám | |
 EDAC Inc. | Solder | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 21 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Single Edge | Single | -40 °C | 105 ░C | Black | 1 | Female | Tin | 0.156 in | 3.96 mm | Through Hole | 1 | |||||
 EDAC Inc. | Solder | Semi Bellows | Floating Bobbin Flush Mount | 21 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Single Edge | Single | -40 °C | 105 ░C | Black | 1 | Female | Gold | 0.156 in | 3.96 mm | Through Hole Right Angle | 1 | 2.95 mm | 0.116 in | 10 Áin | 0.25 Ám | |
 EDAC Inc. | Solder Eyelet(s) | Semi Bellows | Floating Bobbin Flush Mount | 42 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Dual Edge | Dual | -40 °C | 105 ░C | Black | 2 | Female | Gold | 0.156 in | 3.96 mm | Through Hole | 1 | 2.95 mm | 0.116 in | 10 Áin | 0.25 Ám | |
 EDAC Inc. | Solder | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 21 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Single Edge | Single | -40 °C | 105 ░C | Black | 1 | Female | Gold | 0.156 in | 3.96 mm | Through Hole | 1 | 10 Áin | 0.25 Ám | Card Guides | ||
 EDAC Inc. | Solder | Semi Bellows | Flush Mount Side Opening Unthreaded | 21 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Single Edge | Single | -40 °C | 105 ░C | Black | 1 | Female | Tin | 0.156 in | 3.96 mm | Through Hole | 1 | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Solder Eyelet(s) | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 42 | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Polyester Thermoplastic | Non Specified - Dual Edge | Dual | -40 °C | 105 ░C | Black | 2 | Female | Gold | 0.156 in | 3.96 mm | Surface Mount | 1 | 10 Áin | 0.25 Ám | Card Guides |
