1N1190 Series

Catalog

DIODE SWITCHING 600V 35A 2-PIN DO-5

Part	Current - Average Rectified (Io)	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Supplier Device Package	Voltage - DC Reverse (Vr) (Max) [Max]	Technology	Package / Case	Current - Reverse Leakage @ Vr	Speed [Min]	Mounting Type	Voltage - Forward (Vf) (Max) @ If [Max]
GeneSiC Semiconductor 1N1190	35 A	190 °C	-65 C	DO-5	600 V	Standard	DO-203AB DO-5 Stud	10 µA	200 mA 500 ns	Chassis Stud Mount
GeneSiC Semiconductor 1N1190A	40 A	190 °C	-65 C	DO-5	600 V	Standard	DO-203AB DO-5 Stud	10 µA	200 mA 500 ns	Chassis Stud Mount	1.1 V
