T 3363 Series
Manufacturer: Amphenol Tuchel Industrial
Beta
⌘K
CONN RCPT FMALE 5P SILVER SOLDER
| Part | Voltage Rating | Shell Finish | Orientation | Ingress Protection | Primary Material | Shell Material | Shielding | Shell Size - Insert | Mounting Type | Fastening Type | Current Rating (Amps) | Contact Finish - Mating | Termination | Color | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Insert Material | Contact Size | Mounting Feature | Material Flammability Rating | Contact Shape | Housing Color | Contact Type | Note | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount Through Hole | Threaded | 7 A | Silver | Solder | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | |||||||||
 Amphenol Tuchel Industrial | Nickel | Keyed | IP40 | Die Cast | Shielded | M16-5 | Panel Mount | Threaded | Receptacle Housing | -40 C | 100 °C | 5 | Thermoplastic | 1.5 mm | Bulkhead - Front Side Nut | UL94 V-0 | Circular | Silver | Crimp | Contacts Not Included | For Female Sockets | ||||||
Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount | Threaded | 7 A | Silver | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | Bulkhead - Front Side Nut | |||||||||
 Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount | Threaded | 7 A | Gold | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | ||||||||||
 Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount Through Hole | Threaded | 7 A | Silver | Solder | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | |||||||||
 Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount Through Hole | Threaded | 7 A | Gold | Solder | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | |||||||||
Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount Through Hole | Threaded | 7 A | Silver | Solder | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | |||||||||
 Amphenol Tuchel Industrial | Nickel | Keyed | IP40 | Die Cast | Shielded | M16-5 | Panel Mount | Threaded | Receptacle Housing | -40 C | 100 °C | 5 | Thermoplastic | 1.5 mm | Bulkhead - Rear Side Nut | UL94 V-0 | Circular | Silver | Crimp | Contacts Not Included | For Female Sockets | ||||||
 Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount Through Hole | Threaded | 7 A | Silver | Solder | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 | |||||||||
 Amphenol Tuchel Industrial | 250 V | Nickel | Keyed | IP40 | Metal | Die Cast | Shielded | M16-5 | Panel Mount Through Hole | Threaded | 7 A | Silver | Solder | Silver | Receptacle Female Sockets | -40 C | 100 °C | 5 |
