SDER041B Series

Catalog

FIXED IND 15UH 1.05A 407MOHM SMD

Part	Shielding	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Current Rating (Amps)	Current - Saturation (Isat)	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Operating Temperature [Min]	Operating Temperature [Max]	Tolerance	DC Resistance (DCR) [Max]	Inductance Frequency - Test	Mounting Type	Package / Case	Inductance
Delta Electronics/Cyntec SDER041B-150MS	Shielded	0.157 "	4 mm	0.157 in	4 mm	1.05 A	720 mA	1.2 mm	0.047 "	-55 C	125 °C	20 %	407 mOhm	100 kHz	Surface Mount	Nonstandard	15 µH
Delta Electronics/Cyntec SDER041B-220MS	Shielded	0.157 "	4 mm	0.157 in	4 mm	950 mA	630 mA	1.2 mm	0.047 "	-55 C	125 °C	20 %	492 mOhm	100 kHz	Surface Mount	Nonstandard	22 µH
Delta Electronics/Cyntec SDER041B-470MS	Shielded	0.157 "	4 mm	0.157 in	4 mm	0.5 A	410 mA	1.2 mm	0.047 "	-55 C	125 °C	20 %	1.02 Ohm	100 kHz	Surface Mount	Nonstandard	47 µH
Delta Electronics/Cyntec SDER041B-4R7MS	Shielded	0.157 "	4 mm	0.157 in	4 mm	1.9 A	1.3 A	1.2 mm	0.047 "	-55 C	125 °C	20 %	131 mOhm	100 kHz	Surface Mount	Nonstandard	4.7 ÁH
