MAX4688 Series

Catalog

IC SW SPDT-NO/NCX1 2.5OHM 6UCSP

Part	Operating Temperature [Max]	Operating Temperature [Min]	Switch Circuit	Charge Injection	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Crosstalk	Multiplexer/Demultiplexer Circuit	On-State Resistance (Max) [Max]	Number of Circuits	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Channel-to-Channel Matching (ΔRon)	Package / Case	-3db Bandwidth	Current - Leakage (IS(off)) (Max)	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Mounting Type
Analog Devices Inc./Maxim Integrated MAX4688EBT-T	85 °C	-40 °C	SPDT - NO/NC	40 pC	12 pF	12 pF	12 ns	30 ns	-95 dB	2:1	2.5 Ohms	1	1.57	1.05	6-UCSP	300 mOhm	6-WFBGA CSPBGA	200 MHz	500 pA	1.8 V	5.5 V	Surface Mount
Analog Devices Inc./Maxim Integrated MAX4688EBT+T	85 °C	-40 °C	SPDT	40 pC	12 pF	12 pF	12 ns	30 ns	-95 dB	2:1	2.5 Ohms	1			6-WLP	300 mOhm	6-WFBGA WLBGA	200 MHz	500 pA	1.8 V	5.5 V	Surface Mount
