TB6562 Series
Manufacturer: Toshiba Semiconductor and Storage
Beta
⌘K
IC MTR DRV BIPOLAR 10-34V 24SDIP
| Part | Technology | Interface | Supplier Device Package | Current - Output | Package / Case | Package / Case | Package / Case | Output Configuration | Voltage - Supply [Max] | Voltage - Supply [Min] | Voltage - Load [Min] | Voltage - Load [Max] | Step Resolution | Step Resolution | Function | Motor Type - Stepper | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Mounting Type | Motor Type - AC, DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Toshiba Semiconductor and Storage | DMOS | Parallel | 24-SDIP | 1.5 A | 24-SDIP | 7.62 mm | 0.3 in | Half Bridge (4) | 34 VDC | 10 VDC | 10 V | 34 V | 1/2 1/4 | 1 | Driver - Fully Integrated Control and Power Stage | Bipolar | 85 C | -20 °C | General Purpose | Through Hole | |
Toshiba Semiconductor and Storage | DMOS | Parallel | 24-SDIP | 1.5 A | 24-SDIP | 7.62 mm | 0.3 in | Half Bridge (4) | 34 VDC | 10 VDC | 10 V | 34 V | 1/2 1/4 | 1 | Driver - Fully Integrated Control and Power Stage | Bipolar | 150 °C | -20 °C | General Purpose | Through Hole | Brushed DC |
 Toshiba Semiconductor and Storage | DMOS | Parallel | 30-SSOP | 1.5 A | 30-BSOP (0.295" 7.50mm Width) | Half Bridge (4) | 34 VDC | 10 VDC | 10 V | 34 V | 1/2 1/4 | 1 | Driver - Fully Integrated Control and Power Stage | Bipolar | 85 C | -20 °C | General Purpose | Surface Mount |
