2105-7521 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMB F RA NA CR 2.6/50S
| Part | Body Material | Body Finish | Mating Cycles | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Center Contact Plating | Voltage Rating | Fastening Type | Center Contact Material | Contact Termination | Housing Color | Connector Style | Number of Ports | Mounting Type | Connector Type | Shield Termination | Cable Group | Frequency - Max [Max] | Impedance | Insertion Loss | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Brass | Nickel | 500 | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Gold | 335 V | Snap-On | Beryllium Copper | Crimp | Silver | SMB | 1 | Free Hanging (In-Line) Right Angle | Female Socket Plug | Crimp | RG-174 RG-179 RG-316 | 4 GHz | 50 Ohms | ||
 Radiall USA, Inc. | Brass | Nickel | 500 | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Gold | 250 V | Snap-On | Beryllium Copper | Crimp | Silver | SMB | 1 | Free Hanging (In-Line) Right Angle | Female Socket Plug | Crimp | RG-178 | 4 GHz | 50 Ohms | 0.6 dB | 196 |
 Radiall USA, Inc. | Brass | Nickel | 500 | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Gold | 250 V | Snap-On | Beryllium Copper | Crimp | Silver | SMB | 1 | Free Hanging (In-Line) Right Angle | Female Socket Plug | Crimp | RD-178 196 Double Braid | 4 GHz | 50 Ohms | 0.6 dB | |
Radiall USA, Inc. | Brass | Nickel | 500 | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Gold | 335 V | Snap-On | Beryllium Copper | Crimp | Silver | SMB | 1 | Free Hanging (In-Line) Right Angle | Female Socket Plug | Crimp | RD-316 | 4 GHz | 50 Ohms | ||
 Radiall USA, Inc. | Brass | Nickel | 500 | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Gold | 250 V | Snap-On | Beryllium Copper | Crimp | Silver | SMB | 1 | Free Hanging (In-Line) Right Angle | Female Socket Plug | Crimp | RG-178 | 4 GHz | 50 Ohms | ||
 Radiall USA, Inc. | Brass | Nickel | 500 | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | Gold | 250 V | Snap-On | Beryllium Copper | Crimp | Silver | SMB | 1 | Free Hanging (In-Line) Right Angle | Female Socket Plug | Crimp | RG-178 Double Braid | 4 GHz | 50 Ohms | 0.6 dB |
