95727 Series

Catalog

CONN HEADER VERT 72POS 2.54MM

Part	Insulation Height	Insulation Height	Contact Material	Contact Shape	Number of Rows	Contact Type	Material Flammability Rating	Contact Length - Mating [x]	Contact Length - Mating [x]	Connector Type	Number of Positions Loaded	Pitch - Mating	Pitch - Mating	Number of Positions	Mounting Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post [x]	Contact Length - Post	Fastening Type	Overall Contact Length	Overall Contact Length	Shrouding	Termination	Contact Finish - Mating
Amphenol ICC (FCI) 95727-472H	0.1 in	2.54 mm	Phosphor Bronze	Square	2	Male Pin	UL94 V-0	0.615 "	15.62 mm	Header	All	0.1 in	2.54 mm	72	Through Hole	2.54 mm	0.1 in	Black	2.54 çm	100 çin	0.11 in	2.79 mm	Push-Pull	20.95 mm	0.825 in	Unshrouded	Solder
Amphenol ICC (FCI) 95727-172HLF	0.1 in	2.54 mm	Phosphor Bronze	Square	2	Male Pin	UL94 V-0	0.615 "	15.62 mm	Header	All	0.1 in	2.54 mm	72	Through Hole	2.54 mm	0.1 in	Black	0.76 Ám	30 Áin	0.11 in	2.79 mm	Push-Pull	20.95 mm	0.825 in	Unshrouded	Solder	Gold or Gold GXT™
