SS-7488 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
CONN MOD JACK 8P8C R/A SHIELDED
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Housing Material | Number of Positions/Contacts | Mounting Type | Shielding | Orientation | Number of Ports | Termination | Features | Number of Rows | Contact Material | Connector Type | LED Color | Contact Finish | Tab Direction | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 1 | Solder | Board Lock | 1 | Copper Alloy | Jack | Green Red | Gold | Down | |
 Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | Unshielded | 90 ° | 4 | Solder | Board Guide | 1 | Copper Alloy | Jack | Green - Yellow | Gold | Down | |
 Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 1 | Solder | Board Lock | 1 | Copper Alloy | Jack | Green - Green | Gold | Down | |
 Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 2 | Solder | Board Guide | 1 | Copper Alloy | Jack | Yellow - Green | Gold | Down | Cat5 |
Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 4 | Solder | Board Guide | 1 | Copper Alloy | Jack | Green - Yellow | Gold | Down | Cat5 |
Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 1 | Solder | Board Lock | 1 | Copper Alloy | Jack | Green Red | Gold | Down | |
Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 1 | Solder | Board Guide | 1 | Copper Alloy | Jack | Yellow Green | Gold | Down | Cat5 |
 Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 4 | Solder | Board Guide | 1 | Copper Alloy | Jack | Green Red | Gold | Down | Cat5 |
Bel Fuse Inc. | 50 µin | 1.27 µm | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 1 | Solder | Board Lock | 1 | Copper Alloy | Jack | Yellow - Green | Gold | Down | Cat5 | ||
 Bel Fuse Inc. | 85 °C | -40 C | 30 Áin | 0.76 Ám | Thermoplastic | 8p8c (RJ45 Ethernet) | Through Hole | EMI Finger Shielded | 90 ° | 4 | Solder | Board Guide | 1 | Copper Alloy | Jack | Yellow - Green | Gold | Down |
