807-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.156
| Part | Gender | Pitch | Pitch | Contact Finish | Termination Rows | Contact Material | Number of Positions/Bay/Row | Material - Insulation | Read Out | Number of Positions | Termination | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Card Type | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Gold | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Dual | 56 | Solder Eyelet(s) | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Green | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | |||||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Gold | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Single | 28 | Solder | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Single Edge | Green | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Tin | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Single | 28 | Solder | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Single Edge | Green | 125 °C | -40 C | 1 | Flush Mount M3 Threaded Insert Top Opening | ||||||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Tin | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Dual | 56 | Solder | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Green | 125 °C | -40 C | 2 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | ||||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Gold | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Single | 28 | Solder | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Single Edge | Green | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | ||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Gold | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Dual | 56 | Solder | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Green | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | ||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Tin | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Single | 28 | Wire Wrap | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Single Edge | Green | 125 °C | -40 C | 1 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Tin | 1 | Copper Alloy | 28 | Diallyl Phthalate (DAP) | Single | 28 | Wire Wrap | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Single Edge | Green | 125 °C | -40 C | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | ||||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Tin | Copper Alloy | 14 | Diallyl Phthalate (DAP) | Dual | 28 | Solder | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Green | 125 °C | -40 C | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 2 | ||||||
 EDAC Inc. | Female | 3.96 mm | 0.156 in | Tin | Copper Alloy | 14 | Diallyl Phthalate (DAP) | Dual | 28 | Solder | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Semi Bellows | Non Specified - Dual Edge | Green | 125 °C | -40 C | 2 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 2 |
