805-83 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 36POS 0.1 GOLD PCB
| Part | Contact Material | Contact Shape | Insulation Material | Connector Type | Contact Finish - Mating | Contact Length - Post | Contact Length - Post | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Contact Type | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Insulation Color | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Number of Positions Loaded | Number of Rows [custom] | Current Rating (Amps) | Insulation Height | Insulation Height | Number of Positions | Material Flammability Rating | Fastening Type | Termination | Row Spacing - Mating | Row Spacing - Mating | Number of Positions Loaded | Contact Length - Post [x] | Contact Length - Post [x] | Insulation Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | 0.121 in | 3.08 mm | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 0.312 in | 7.92 mm | 36 | UL94 V-0 | Push-Pull | Solder | ||||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | -55 C | 125 °C | Through Hole | Tin | 0.2 " | 5.08 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 3 | 3 A | 0.165 in | 4.2 mm | 51 | UL94 V-0 | Push-Pull | Solder | 5.08 mm | 0.2 in | 18 | 0.126 " | 3.2 mm | ||||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | 0.125 in | 3.18 mm | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 0.165 in | 4.2 mm | 90 | UL94 V-0 | Push-Pull | Solder | ||||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | 0.116 in | 2.95 mm | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 8.4 mm | 75 | UL94 V-0 | Push-Pull | Solder | 0.331 in | ||||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | 0.118 in | 3 mm | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 0.276 in | 7 mm | 30 | UL94 V-0 | Push-Pull | Solder | ||||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 0.272 in | 6.91 mm | 30 | UL94 V-0 | Push-Pull | Solder | 0.122 in | 3.1 mm | ||||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | 0.116 in | 2.95 mm | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 8.4 mm | 9 | UL94 V-0 | Push-Pull | Solder | 0.331 in | ||||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | 0.116 in | 2.95 mm | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 8.4 mm | 39 | UL94 V-0 | Push-Pull | Solder | 0.331 in | ||||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | -55 C | 125 °C | Through Hole | Tin | 0.1 " | 2.54 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 0.1 in | 2.54 mm | All | 3 | 3 A | 0.272 in | 6.91 mm | 48 | UL94 V-0 | Push-Pull | Solder | 0.122 in | 3.1 mm | ||||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Socket | Gold | -55 C | 125 °C | Through Hole | Tin | 0.2 " | 5.08 mm | Female Socket | 29.5 µin | 0.75 µm | Black | 3 | 3 A | 0.165 in | 4.2 mm | 69 | UL94 V-0 | Push-Pull | Solder | 5.08 mm | 0.2 in | 24 | 0.126 " | 3.2 mm |
