29400 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE SPST 50MA 24V
| Part | Coil Resistance | Contact Rating (Current) | Contact Material | Coil Current | Features | Relay Type | Contact Form | Coil Type | Release Time | Coil Voltage | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Switching Voltage [Max] | Operate Time | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 1.14 kOhms | 50 mA | Gold (Au) Silver Palladium (AgPd) | 21 mA | Lighted Indicator Socket Included | General Purpose | SPST-NO (1 Form A) | Non Latching | 11 ms | 24 VDC | cURus EAC UR | -20 ░C | 40 °C | Screw Terminal | 30 VAC 36 VDC | 7 ms | DIN Rail |
 Phoenix Contact | 1143 Ohms | 50 mA | Gold (Au) Silver Palladium (AgPd) | 21 mA | Lighted Indicator Socket Included | General Purpose | SPDT (1 Form C) | Non Latching | 11 ms | 24 VDC | -20 ░C | 40 °C | Screw Terminal | 30 VAC 36 VDC | 7 ms | DIN Rail |
