QT20 Series

Manufacturer: PULS, LP

Catalog

AC/DC DIN RAIL SUPPLY 36V 480W

Part	Number of Outputs	Voltage - Isolation	Efficiency	Power (Watts)	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Current - Output (Max) [Max]	Applications	Standard Number	Approval Agency	Operating Temperature [Max]	Operating Temperature [Min]	Input Type	Voltage - Output 1 [custom]	Features	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Voltage - Output 1
PULS, LP QT20.361	1	500 V	94.6 %	480 W	323 VAC	552 VAC	13.3 A	ITE (Commercial)	508 60950-1 61010-2-201 Class I Div 2	ABS CSA DNV GL EAC IEC UL	70 °C	-10 °C	AC	36 V	Adjustable Output Load Sharing PFC	124 mm	127 mm	65 mm	2.56 in	5 "	4.88 in
PULS, LP QT20.241-C1	1	500 V	94.8 %	480 W	323 VAC	552 VAC	20 A	ITE (Commercial)	50155 508 60950-1 61010-2-201 Class I Div 2 F47	ABS CSA DNV GL EAC EN IEC SEMI UL	70 °C	-10 °C	AC		Adjustable Output Conformal Coating Load Sharing PFC	124 mm	127 mm	65 mm	2.56 in	5 "	4.88 in	24 V
PULS, LP QT20.241	1	500 V	95 %	480 W	323 VAC	552 VAC	20 A	ITE (Commercial)	508 60950-1 61010-2-201 Class I Div 2 F47	ABS CSA DNV GL EAC IEC SEMI UL	70 °C	-10 °C	AC		Adjustable Output Load Sharing PFC	124 mm	127 mm	65 mm	2.56 in	5 "	4.88 in	24 V
PULS, LP QT20.481	1	500 V	95.4 %	480 W	323 VAC	552 VAC	10 A	ITE (Commercial)	508 60950-1 61010-2-201 Class I Div 2	ABS CSA DNV GL EAC IEC UL	70 °C	-10 °C	AC		Adjustable Output Load Sharing PFC	124 mm	127 mm	65 mm	2.56 in	5 "	4.88 in	48 V
