E2B-M18 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 5MM CYLIND
| Part | Material - Body | Sensor Type | Sensing Distance | Sensing Distance | Shielding | Response Frequency | Output Type | Ingress Protection | Indicator | Package / Case | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Nickel-Plated Brass | Inductive | 5 mm | 0.197 in | Shielded | 600 Hz | 3-Wire NPN-NO | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | |
 Omron Automation and Safety | Nickel-Plated Brass | Inductive | 10 mm | 0.394 in | Unshielded | 400 Hz | 3-Wire NPN-NO | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | |
 Omron Automation and Safety | Nickel-Plated Brass | Inductive | 16 mm | 0.63 in | Unshielded | 400 Hz | 3-Wire NPN-NC | IP67 | LED | Cylinder Threaded - M18 | Connector | -25 °C | 70 °C | 10 VDC | 30 VDC | |
 Omron Automation and Safety | Nickel-Plated Brass | Inductive | 16 mm | 0.63 in | Unshielded | 400 Hz | 3-Wire NPN-NO | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | |
 Omron Automation and Safety | Nickel-Plated Brass | Inductive | 8 mm | 0.315 in | Shielded | 500 Hz | 3-Wire NPN-NC | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | |
Omron Automation and Safety | Nickel-Plated Brass | Inductive | 10 mm | 0.394 in | Unshielded | 400 Hz | PNP-NO | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | 3 |
Omron Automation and Safety | Nickel-Plated Brass | Inductive | 5 mm | 0.197 in | Shielded | 600 Hz | 3-Wire NPN-NO | IP67 | LED | Cylinder Threaded - M18 | Connector | -25 °C | 70 °C | 10 VDC | 30 VDC | |
Omron Automation and Safety | Nickel-Plated Brass | Inductive | 10 mm | 0.394 in | Unshielded | 400 Hz | 3-Wire NPN-NC | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | |
 Omron Automation and Safety | Nickel-Plated Brass | Inductive | 8 mm | 0.315 in | Shielded | 500 Hz | PNP-NO | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC | 3 |
Omron Automation and Safety | Nickel-Plated Brass | Inductive | 10 mm | 0.394 in | Unshielded | 400 Hz | 3-Wire NPN-NO | IP67 | LED | Cylinder Threaded - M18 | Cable Leads | -25 °C | 70 °C | 10 VDC | 30 VDC |
