346-046 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 46POS 0.125
...
| Part | Contact Material | Color | Contact Finish | Number of Positions/Bay/Row [custom] | Termination | Termination Rows | Flange Feature | Flange Feature | Card Type | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Read Out | Pitch [x] | Pitch [x] | Contact Type | Number of Rows | Number of Positions | Mounting Type | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder | 2 | 3.25 mm | 0.128 in | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Through Hole | Polyester Thermoplastic | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | Copper Alloy | Green | Gold | 46 | Solder Eyelet(s) | 1 | Non Specified - Single Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 0.125 in | 3.18 mm | Cantilever | 1 | 46 | Through Hole | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Copper Alloy | Green | Gold | 46 | Solder Wire Wrap | 1 | Non Specified - Single Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 0.125 in | 3.18 mm | Cantilever | 1 | 46 | Through Hole Right Angle | Polyester Thermoplastic | 10 Áin | 0.25 Ám | ||||||
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder | 2 | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Through Hole | Polyester Thermoplastic | 10 Áin | 0.25 Ám | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Copper Alloy | Green | Gold | 46 | Solder Wire Wrap | 1 | Non Specified - Single Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Single | 0.125 in | 3.18 mm | Cantilever | 1 | 46 | Through Hole Right Angle | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder | 2 | 3.25 mm | 0.128 in | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Through Hole | Polyester Thermoplastic | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder | 2 | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Through Hole | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder Wire Wrap | 2 | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Through Hole Right Angle | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Flush Mount Top Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder | 2 | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Through Hole | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Flush Mount Top Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Copper Alloy | Green | Gold | 23 | Solder Eyelet(s) | 2 | Non Specified - Dual Edge | Female | -40 °C | 105 ░C | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | 0.125 in | 3.18 mm | Cantilever | 2 | 46 | Board Edge Straddle Mount | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Card Extender |
