C0PPG-1 Series

Catalog

DIP CABLE - CDP14G/AE14M/CDP14G

Part	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Contact Finish	Pitch - Connector	Pitch - Connector	Length [x]	Length [x]	Shielding	Number of Positions	Number of Rows [custom]	Cable Termination	Pitch - Cable	Pitch - Cable	Color	Usage	Length	Length	Length
CW Industries C0PPG-1418M	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm	457.2 mm	1.5 ft	Unshielded	14	2	IDC	0.05 in	1.27 mm	Multiple Ribbon	Board In Socket (0.3")
CW Industries C0PPG-1406G	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm			Unshielded	14	2	IDC	0.05 in	1.27 mm		Board In Socket (0.3")	152.4 mm	0.5 '	6 "
CW Industries C0PPG-1606G	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm			Unshielded	16	2	IDC	0.05 in	1.27 mm		Board In Socket (0.3")	152.4 mm	0.5 '	6 "
CW Industries C0PPG-1636G	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm			Unshielded	16	2	IDC	0.05 in	1.27 mm		Board In Socket (0.3")	91.44 cm	3 ft
CW Industries C0PPG-1636M	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm			Unshielded	16	2	IDC	0.05 in	1.27 mm	Multiple Ribbon	Board In Socket (0.3")	91.44 cm	3 ft
CW Industries C0PPG-1418G	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm	457.2 mm	1.5 ft	Unshielded	14	2	IDC	0.05 in	1.27 mm		Board In Socket (0.3")
CW Industries C0PPG-1606M	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm			Unshielded	16	2	IDC	0.05 in	1.27 mm	Multiple Ribbon	Board In Socket (0.3")	152.4 mm	0.5 '	6 "
CW Industries C0PPG-1618G	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm	457.2 mm	1.5 ft	Unshielded	16	2	IDC	0.05 in	1.27 mm		Board In Socket (0.3")
CW Industries C0PPG-1436M	0.25 Ám	10 Áin	DIP to DIP Reversed	Gold	0.1 in	2.54 mm			Unshielded	14	2	IDC	0.05 in	1.27 mm	Multiple Ribbon	Board In Socket (0.3")	91.44 cm	3 ft
