395-122 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR, 122 CONTACT(S), 2 ROW(S), FEMALE, STRAIGHT, 0.1 INCH PITCH, SOLDER TERMINAL, GUIDE SET, BLACK INSULATOR,
...
| Part | Number of Rows | Termination Rows | Number of Positions | Mounting Type | Termination | Features | Color | Contact Material | Contact Finish | Pitch [x] | Pitch [x] | Read Out | Material - Insulation | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Flange Feature | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Gender | Number of Positions/Bay/Row [custom] | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | 2 | 122 | Through Hole | Solder | Card Guides | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Threaded Insert Top Mount Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | 2 | 2 | 122 | Board Edge Straddle Mount | Solder | Card Extender | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Side Mount Opening Unthreaded | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 in | ||
 EDAC Inc. | 2 | 2 | 122 | Through Hole | Solder | Card Guides | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Threaded Insert Top Mount Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | 2 | 2 | 122 | Through Hole | Wire Wrap | Card Guides | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Threaded Insert Top Mount Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | 2 | 2 | 122 | Through Hole | Wire Wrap | Card Guides | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | 2 | 2 | 122 | Board Edge Straddle Mount | Solder Eyelet(s) | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | |||||
 EDAC Inc. | 2 | 2 | 122 | Board Edge Straddle Mount | Solder Eyelet(s) | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Flush Mount Threaded Insert Top Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | |||||
 EDAC Inc. | 2 | 2 | 122 | Through Hole Right Angle | Solder | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Flush Mount M3 Threaded Insert Top Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | |||||
 EDAC Inc. | 2 | 2 | 122 | Through Hole | Solder | Card Guides | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Threaded Insert Top Mount Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | ||||
 EDAC Inc. | 2 | 2 | 122 | Through Hole Right Angle | Solder | Black | Copper Alloy | Gold | 2.54 mm | 0.1 in | Dual | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Floating Bobbin Top Mount Opening | -40 °C | 105 ░C | Non Specified - Dual Edge | Female | 61 | Cantilever | 10 Áin | 0.25 Ám | 2.95 mm | 0.116 in |
