WIZFI360 Series
Manufacturer: WIZnet
Beta
⌘K
WIFI MODULES - 802.11 LOWPWR COMPACT PIN-HEADER TYPE
| Part | Serial Interfaces | Package / Case | Current - Transmitting | Antenna Type | RF Family/Standard | Voltage - Supply [Max] | Voltage - Supply [Min] | Protocol | Frequency | Operating Temperature [Max] | Operating Temperature [Min] | Data Rate | Mounting Type | Current - Receiving | Frequency [Max] | Frequency [Min] | Modulation | Power - Output | Sensitivity | Supplied Contents | For Use With/Related Products | Type | Utilized IC / Part | Contents | Antenna Type | Platform | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 WIZnet | UART | Module | 230 mA | Integrated Trace | WiFi | 5.5 V | 4.5 V | 802.11b/g/n | 2.4 GHz | 85 °C | -40 C | 2 MBd | Chassis Mount | 110 mA | |||||||||||||
 WIZnet | UART | Module | 230 mA | Integrated Trace | WiFi | 3.6 V | 3 V | 802.11b/g/n | 85 °C | -40 C | 72.2 Mbps | Surface Mount | 110 mA | 2.4835 GHz | 2.4 GHz | CCK DSSS OFDM | 19 dBm | -95 dBm | |||||||||
 WIZnet | 2.4 GHz | Board(s) | WizFi360 | Transceiver; 802.11 b/g/n (Wi-Fi WiFi WLAN) | WizFi360 | Board(s) | |||||||||||||||||||||
 WIZnet | UART | 20-DIP Module | 230 mA | Integrated Trace | WiFi | 3.6 V | 3 V | 802.11b/g/n | 2.4 GHz | 85 °C | -40 C | 2 MBd | Through Hole | 110 mA | |||||||||||||
 WIZnet | UART | Module | 230 mA | I-PEX | WiFi | 3.6 V | 3 V | 802.11b/g/n | 85 °C | -40 C | 72.2 Mbps | Surface Mount | 110 mA | 2.4835 GHz | 2.4 GHz | CCK DSSS OFDM | 19 dBm | -95 dBm | |||||||||
 WIZnet | RF | WizFi360 | Board(s) | Arduino | WiFi |
