T 3507 Series
Manufacturer: Amphenol Tuchel Industrial
Beta
⌘K
CONN RCPT HSNG FMALE 8POS PNL MT
| Part | Note | Operating Temperature [Min] | Operating Temperature [Max] | Insert Material | Contact Shape | Type | Housing Color | Contact Type | Orientation | Mounting Feature | Shielding | Connector Type | Mounting Type | Ingress Protection | Shell Size - Insert | Shell Material | Contact Size | Material Flammability Rating | Fastening Type | Number of Positions | Shell Finish | Contact Finish - Mating | Primary Material | Color | Current Rating (Amps) | Voltage Rating | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Tuchel Industrial | Contacts Not Included | -40 C | 100 °C | Thermoplastic | Circular | For Female Sockets | Silver | Crimp | Keyed | Bulkhead - Front Side Nut | Shielded | Receptacle Housing | Panel Mount | IP40 | M16-8 | Die Cast | 1.5 mm | UL94 V-0 | Threaded | 8 | Nickel | ||||||
 Amphenol Tuchel Industrial | -40 C | 100 °C | Keyed | Shielded | Receptacle Female Sockets | Panel Mount | IP40 | M16-8 | Die Cast | Threaded | 8 | Nickel | Gold | Metal | Silver | 7 A | 250 V | ||||||||||
 Amphenol Tuchel Industrial | -40 C | 100 °C | Keyed | Shielded | Receptacle Female Sockets | Panel Mount Through Hole | IP40 | M16-8 | Die Cast | Threaded | 8 | Nickel | Silver | Metal | Silver | 7 A | 250 V | Solder | |||||||||
 Amphenol Tuchel Industrial | -40 C | 100 °C | Keyed | Shielded | Receptacle Female Sockets | Panel Mount Through Hole | IP40 | M16-8 | Die Cast | Threaded | 8 | Nickel | Silver | Metal | Silver | 7 A | 250 V | Solder |
