T18-2V Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
T18-2 SERIES: FIXED FIELD
| Part | Ingress Protection | Light Source | Sensing Method | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Distance | Sensing Distance | Operating Temperature [Max] | Operating Temperature [Min] | Cable Length | Cable Length | Connection Method | Output Configuration | Response Time | Adjustment Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Background Suppression | 10 VDC | 30 VDC | 200 mm | 7.874 in | 70 °C | -40 C | 78.74 " | 2 m | Cable | NPN - Dark-ON/Light-ON | 1.5 ms | |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Diffuse | 10 VDC | 30 VDC | 750 mm | 29.528 " | 70 °C | -40 C | 78.74 " | 2 m | Cable | NPN - Dark-ON/Light-ON | 1.5 ms | Adjustable Potentiometer |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Polarized Retroreflective | 10 VDC | 30 VDC | 6 m | 236.22 " | 70 °C | -40 C | 78.74 " | 2 m | Cable | PNP - Dark-ON/Light-ON | 1.5 ms | Adjustable Potentiometer |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Diffuse | 10 VDC | 30 VDC | 750 mm | 29.528 " | 70 °C | -40 C | 78.74 " | 2 m | Cable | PNP - Dark-ON/Light-ON | 1.5 ms | Adjustable Potentiometer |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Diffuse | 10 VDC | 30 VDC | 30 cm | 11.811 " | 70 °C | -40 C | 78.74 " | 2 m | Cable | PNP - Dark-ON/Light-ON | 1.5 ms | Adjustable Potentiometer |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Polarized Retroreflective | 10 VDC | 30 VDC | 6 m | 236.22 " | 70 °C | -40 C | 78.74 " | 2 m | Cable | NPN - Dark-ON/Light-ON | 1.5 ms | |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Red (624nm) | Through-Beam | 10 VDC | 30 VDC | 25 m | 82.02 ' | 70 °C | -40 C | Connector | PNP - Dark-ON/Light-ON - Selectable | 1.5 ms | Adjustable Potentiometer | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Background Suppression | 10 VDC | 30 VDC | 10 cm | 3.937 in | 70 °C | -40 C | 78.74 " | 2 m | Cable | PNP - Dark-ON/Light-ON | 1.5 ms | |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP68 IEC IP69K IP67 IP68 IP69K | Red LED | Through-Beam | 10 VDC | 30 VDC | 25 m | 82.02 ' | 70 °C | -40 C | 78.74 " | 2 m | Cable | PNP - Dark-ON/Light-ON | 1.5 ms | |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Red (624nm) | Polarized Retroreflective | 10 VDC | 30 VDC | 6 m | 236.22 " | 70 °C | -40 C | Connector | PNP - Dark-ON/Light-ON - Selectable | 1.5 ms | Adjustable Potentiometer |
