16-002 Series
Manufacturer: Tensility International Corp
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
AC/DC WALL MNT ADPTR 5V-20V 42W
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Applications | Input Type | Region Utilized | Output Connector | No Load Power Consumption (Max) | Current - Output (Max) Options | Voltage - Input (AC) Maximum | Voltage - Input (AC) Minimum | Efficiency | Form | Approval Agency | Input Connector | Size / Dimension Height | Size / Dimension Length | Size / Dimension Width | Standard Number | Power (Watts) | Voltage - Output (5) | Voltage - Output (2) | Voltage - Output (4) | Voltage - Output (1) | Voltage - Output (3) | Voltage - Output |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Tensility International Corp | 0 °C | 35 °C | ITE (Commercial) | Fixed Blade | North America | C Receptacles USB A USB A Receptacle USB C Power Delivery (PD) | 100 mW | 1.5A 2.5A 2A 3A | 240 VAC | 100 VAC | Level VI | Wall Mount (Class II) | cULus FCC | NEMA 1-15P | 1.14 in | 2.58 in | 2.36 in | 62368-1 | 42 W | 20 V | 9 V | 15 V | 5 V | 12 V | |
 Tensility International Corp | 0 °C | 35 °C | ITE (Commercial) | Fixed Blade | North America | USB C Power Delivery (PD) USB C Receptacle | 100 mW | 1.5A 2A 3A | 240 VAC | 100 VAC | Level VI | Wall Mount (Class II) | cULus FCC | NEMA 1-15P | 1.14 in | 2.36 in | 1.74 in | 62368-1 | 18 W | 5 VDC 9 V 12 V |
