Q5-3X Series
Manufacturer: Qualtek
Beta
⌘K
HEAT SHRINK TUBING & SLEEVES 3/4 6IN 12PC BAG BLACK
| Part | Material | Recovered Wall Thickness | Recovered Wall Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Shrink Temperature | Shelf Life | Shrinkage Ratio | Color | Inner Diameter - Recovered [diameter] | Inner Diameter - Recovered [diameter] | Features | Length | Length | Length | Type | Storage/Refrigeration Temperature [Max] | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Max] | Inner Diameter - Supplied [diameter] | Inner Diameter - Supplied [diameter] | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Qualtek | Polyolefin (PO) | 0.084 in | 2.13 mm | -55 C | 125 °C | 80 °C | 60 Months | 3 to 1 | Black | 5.99 mm | 0.236 in | Adhesive Lined Flame Retardant | 152.4 mm | 0.5 ' | 6 " | Tubing Flexible | 40 °C | 14 °F | -50 °F | 40 °C | ||||
 Qualtek | Polyolefin (PO) | 0.094 in | 2.4 mm | -55 C | 125 °C | 80 °C | 60 Months | 3 to 1 | Black | 8 mm | 0.315 in | Adhesive Lined Flame Retardant | 25 m | 82 ft | Tubing Flexible | 40 °C | 14 °F | -50 °F | 40 °C | 0.945 " | 24 mm | |||
 Qualtek | Polyolefin (PO) | 0.055 in | 1.4 mm | -55 C | 125 °C | 80 °C | 60 Months | 3 to 1 | Black | 2.99 mm | 0.118 in | Adhesive Lined Flame Retardant | Tubing Flexible | 40 °C | 14 °F | -50 °F | 40 °C | 0.354 in | 8.99 mm | 4 ft | 1.22 m |
