36 Series
Manufacturer: Murata Electronics
Beta
⌘K
FIXED IND 2.3UH 6A 20 MOHM SMD
| Part | Package / Case | Tolerance | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Type | DC Resistance (DCR) [Max] | Shielding | Mounting Type | Height - Seated (Max) | Height - Seated (Max) [Max] [z] | Current Rating (Amps) | Inductance | Operating Temperature [Max] | Operating Temperature [Min] | DC Resistance (DCR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | 20 mOhm | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 6 A | 2.3 µH | 125 °C | -40 C | |
 Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | 35 mOhm | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 4.6 A | 3.3 µH | 125 °C | -40 C | |
Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 9.5 A | 1 µH | 125 °C | -40 C | 7.5 mOhm | |
Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 7 A | 1.8 µH | 125 °C | -40 C | 14 mOhm | |
Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | 5 mOhm | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 12.5 Amps | 600 nH | 125 °C | -40 C | |
 Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | 41 mOhm | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 3.6 A | 4.7 ÁH | 125 °C | -40 C | |
 Murata Electronics | Nonstandard | 25 % | 6.8 mm | 0.268 " | 0.268 in | 6.8 mm | Wirewound | 4 mOhm | Unshielded | Surface Mount | 4.2 mm | 0.165 " | 14.5 A | 400 nH | 125 °C | -40 C |
