357-058 Series
Manufacturer: EDAC Inc.
Catalog
357 SERIES (.156" (3.96MM) CONTA
...
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Gender | Contact Type | Termination Rows | Pitch [x] | Pitch [x] | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Number of Rows | Contact Finish | Contact Material | Termination | Card Type | Material - Insulation | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Read Out | Color | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 3.25 mm | 0.128 " | Flush Mount Top Opening Unthreaded | 2 | Gold | Copper Alloy | Solder | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | |
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Tin | Copper Alloy | Solder | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | Card Guides | ||||
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Gold | Copper Alloy | Solder | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | Card Guides | ||
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Board Edge Straddle Mount | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Gold | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | Card Extender | ||
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Through Hole Right Angle | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 3.25 mm | 0.128 " | Flush Mount Top Opening Unthreaded | 2 | Gold | Copper Alloy | Solder Wire Wrap | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | |
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Gold | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | Card Guides | ||
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 3.25 mm | 0.128 " | Flush Mount Top Opening Unthreaded | 2 | Gold | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | |
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 2.95 mm | 0.116 in | Floating Bobbin Flush Mount | 2 | Tin | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | |||
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | Through Hole | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Tin | Copper Alloy | Solder Eyelet(s) | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black | Card Guides | ||||
 EDAC Inc. | -40 °C | 105 ░C | 29 | 58 | 10 Áin | 0.25 Ám | Through Hole Right Angle | Female | Semi Bellows | 2 | 0.156 in | 3.96 mm | 2 | Gold | Copper Alloy | Solder Wire Wrap | Non Specified - Dual Edge | Polyester Thermoplastic | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Dual | Black |
