172-050 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, DB50, RECEPTACLE, 172 M SERIES, 50 CONTACTS, DD, THROUGH HOLE
| Part | Dielectric Material | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Color | Material Flammability Rating | Connector Type | Contact Finish Thickness | Mounting Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Shell Material, Finish | Number of Rows [custom] | Connector Style | Number of Positions | Current Rating (Amps) | Contact Type | Flange Feature | Termination | Contact Finish | Features | Shell Material, Finish [custom] | Shell Material, Finish [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 125 °C | -50 °C | Black | UL94 V-0 | Receptacle Female Sockets | Flash | Panel Mount Through Hole | 5 | D DD | Nickel Plated Steel | 3 | D-Sub | 50 | 5 A | Signal | Board Side (4-40) | Solder | Gold | |||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Polyester | Brass | 100 °C | -50 °C | Beige | UL94 V-0 | Receptacle Female Sockets | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | Board Side (4-40) | Solder | Gold | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Polyester | Brass | 100 °C | -50 °C | Beige | UL94 V-0 | Plug Male Pins | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | 4-40 | Wire Wrap | Gold | Grounding Indents | |||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 125 °C | -50 °C | UL94 V-0 | Plug Male Pins | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | 4-40 | Solder | Gold | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Polyester | Brass | 100 °C | -50 °C | Beige | UL94 V-0 | Receptacle Female Sockets | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | 4-40 | Solder | Gold | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Polyester | Brass | 100 °C | -50 °C | Beige | UL94 V-0 | Plug Male Pins | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | Board Side (4-40) | Solder | Gold | Grounding Indents | |||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | UL94 V-0 | Receptacle Female Sockets | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | 4-40 | Solder | Gold | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | UL94 V-0 | Plug Male Pins | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | 4-40 | Solder | Gold | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) Polyester | Brass | 100 °C | -50 °C | Beige | UL94 V-0 | Plug Male Pins | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | Housing/Shell (Unthreaded) | Wire Wrap | Gold | Grounding Indents | |||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | UL94 V-0 | Plug Male Pins | Flash | Panel Mount Through Hole | 5 | D DD | 3 | D-Sub | 50 | 5 A | Signal | Board Side (4-40) | Solder | Gold | Grounding Indents |
