346-010 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 10 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
...
| Part | Features | Number of Positions/Bay/Row [custom] | Mounting Type | Contact Material | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Gender | Pitch [x] | Pitch [x] | Termination Rows | Card Type | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Color | Termination | Material - Insulation | Flange Feature | Contact Finish | Number of Rows | Read Out | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Card Extender | 5 | Board Edge Straddle Mount | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 2 | Non Specified - Dual Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 2 | Dual | 10 | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 10 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 1 | Non Specified - Single Edge | Cantilever | -40 °C | 105 ░C | Green | Wire Wrap | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | Gold | 1 | Single | 10 | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " | |
 EDAC Inc. | Card Guides | 5 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 2 | Non Specified - Dual Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Gold | 2 | Dual | 10 | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | Card Guides | 5 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 2 | Non Specified - Dual Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | 4-40 Threaded Insert Top Mount Opening | Gold | 2 | Dual | 10 | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 10 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 1 | Non Specified - Single Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | Gold | 1 | Single | 10 | 10 Áin | 0.25 Ám | 3.96 mm | 0.156 in | |
 EDAC Inc. | 10 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 1 | Non Specified - Single Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 1 | Single | 10 | 10 Áin | 0.25 Ám | |||
 EDAC Inc. | Card Extender | 5 | Board Edge Straddle Mount | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 2 | Non Specified - Dual Edge | Cantilever | -40 °C | 105 ░C | Green | Solder Eyelet(s) | Polyester Thermoplastic | Flush Mount M3 Threaded Insert Top Opening | Gold | 2 | Dual | 10 | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | Card Extender | 5 | Board Edge Straddle Mount | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 2 | Non Specified - Dual Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | Flush Mount M3 Threaded Insert Top Opening | Gold | 2 | Dual | 10 | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 10 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 1 | Non Specified - Single Edge | Cantilever | -40 °C | 105 ░C | Green | Solder | Polyester Thermoplastic | Floating Bobbin Flush Mount | Gold | 1 | Single | 10 | 10 Áin | 0.25 Ám | 2.95 mm | 0.116 in | |
 EDAC Inc. | 5 | Through Hole | Copper Alloy | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Female | 0.125 in | 3.18 mm | 2 | Non Specified - Dual Edge | Cantilever | -40 °C | 105 ░C | Green | Solder Eyelet(s) | Polyester Thermoplastic | Flush Mount Side Opening Unthreaded | Gold | 2 | Dual | 10 | 10 Áin | 0.25 Ám | 3.25 mm | 0.128 " |
