BPWX 1 Series

Catalog

AC/DC CONVERTER 8V 5V 1.3W

Part	Mounting Type	Voltage - Input [Max]	Voltage - Input [Min]	Current - Output (Max)	Type	Package / Case	Power (Watts)	Efficiency	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Voltage - Output 1	Applications
Cita Technologies, LLC. BPWX 1-08-50	Through Hole	308 VAC	90 VAC	83 mA 125 mA	Enclosed	7-DIP Module	1.3 W	70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	2	85 °C	-40 C	CB cURus	8 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-14-50	Through Hole	308 VAC	90 VAC	28 mA 71 mA	Enclosed	7-DIP Module	747 mW	70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	2	85 °C	-40 C	CB cURus	14 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-08-33	Through Hole	308 VAC	90 VAC	53 mA 125 mA	Enclosed	7-DIP Module	837 mW	70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	2	85 °C	-40 C	CB cURus	8 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-14-33	Through Hole	308 VAC	90 VAC	23 mA 71 mA	Enclosed	7-DIP Module	556 mW	70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	2	85 °C	-40 C	CB cURus	14 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-14-00	Through Hole	308 VAC	90 VAC		Enclosed	7-DIP Module		70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	1	85 °C	-40 C	CB cURus	14 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-12-00	Through Hole	308 VAC	90 VAC		Enclosed	7-DIP Module		70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	1	85 °C	-40 C	CB cURus	12 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-08-00	Through Hole	308 VAC	90 VAC		Enclosed	7-DIP Module		70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	1	85 °C	-40 C	CB cURus	8 V	ITE (Commercial)
Cita Technologies, LLC. BPWX 1-16-00	Through Hole	308 VAC	90 VAC		Enclosed	7-DIP Module		70 %	0.92 "	23.2 mm	1.1 in	0.55 in	14 mm	27.9 mm	1	85 °C	-40 C	CB cURus	16 V	ITE (Commercial)
