Isolated DC/DC Converters - Chassis Mount DC-DC Converter with Cover, 30-50 Watt, 10:1 Input, 16.8-160Vin, 5Vout, 83%, 10000uF, Negative Logic Remote ON/OFF
Isolated DC/DC Converters - Chassis Mount DC-DC Converter with Cover, 30-50 Watt, 10:1 Input, 16.8-160Vin, 5Vout, 83%, 10000uF, Negative Logic Remote ON/OFF
Isolated DC/DC Converters - Chassis Mount DC-DC Converter with Cover, 30-50 Watt, 10:1 Input, 16.8-160Vin, 5Vout, 83%, 10000uF, Negative Logic Remote ON/OFF
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Efficiency | Voltage - Input (Max) [Max] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Isolation | Mounting Type | Applications | Type | Current - Output (Max) [Max] | Number of Outputs | Standard Number | Voltage - Output 1 | Approval Agency | Power (Watts) | Voltage - Input (Min) [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | -40 °C | 100 °C | 83 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) Railway | Enclosed | 6 A | 1 | 60950-1 | 5 V | CE UKCA | 50 W | 14 V |
 Cincon Electronics Co. LTD | -40 °C | 100 °C | 89 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) Railway | Enclosed | 2.1 A | 1 | 60950-1 | 24 V | CE UKCA | 50 W | 14 V |
Cincon Electronics Co. LTD | -40 °C | 100 °C | 87 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) | Enclosed | 4.2 A | 1 | 60950-1 | 12 V | CE UKCA | 50 W | 14 V |
Cincon Electronics Co. LTD | -40 °C | 100 °C | 89 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) | Enclosed | 2.1 A | 1 | 60950-1 | 24 V | CE UKCA | 50 W | 14 V |
Cincon Electronics Co. LTD | -40 °C | 100 °C | 87 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) | Enclosed | 4.2 A | 1 | 60950-1 | 12 V | CE UKCA | 50 W | 14 V |
Cincon Electronics Co. LTD | -40 °C | 100 °C | 88 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) Railway | Enclosed | 1.05 A | 1 | 60950-1 | 48 V | CE UKCA | 50 W | 14 V |
Cincon Electronics Co. LTD | -40 °C | 100 °C | 88 % | 160 V | 34.3 mm | 116.8 mm | 1.35 in | 2.49 in | 63.2 mm | 4.6 " | 3000 V | Chassis Mount | ITE (Commercial) Railway | Enclosed | 1.05 A | 1 | 60950-1 | 48 V | CE UKCA | 50 W | 14 V |
