DCDA Series

Catalog

MICRO D CABLE ASSEMBLY, MIL-DTL-83513, MICRO-D RECEPTACLE TO FREE END, 25 POSITIONS, 18 ", 457.2 MM

Part	Shielding	Length [x]	Length [x]	1st Connector	Contact Finish Thickness	Contact Finish Thickness	2nd Connector	Contact Finish	Type	Number of Positions	Color	Length	Length	Shell Material, Finish	Mounting Type	Shell Size, Connector Layout [y]	Shell Size, Connector Layout [x]	Connector Type	Connector Style	Primary Material	Number of Rows [custom]	Flange Feature	Contact Type	Current Rating (Amps)	Contact Material	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]
Cinch Connectivity Solutions DCDA25S6E5-18.0B	Unshielded	457.2 mm	1.5 ft	Receptacle Female Sockets	50 µin	1.27 µm	Individual Wire Leads	Gold	D-Type Micro-D	25	Individual Multiple
Cinch Connectivity Solutions DCDA37P6E5-36.0B	Unshielded			Male Pins Plug	50 µin	1.27 µm	Individual Wire Leads	Gold	D-Type Micro-D	37	Individual Multiple	91.44 cm	3 ft
Cinch Connectivity Solutions DCDA15S6E5-36.0B	Unshielded			Receptacle Female Sockets	50 µin	1.27 µm	Individual Wire Leads	Gold	D-Type Micro-D	15	Individual Multiple	91.44 cm	3 ft
Cinch Connectivity Solutions DCDA9PSB								Gold		9				Plastic	Panel Mount	0.043 in	0.05 in	Plug Male Pins	D-Type Micro-D	Plastic	2	Housing/Shell (Unthreaded)	Signal	3 A
Cinch Connectivity Solutions DCDA15PSB								Gold		15				Plastic	Panel Mount	0.043 in	0.05 in	Plug Male Pins	D-Type Micro-D	Plastic	2	Housing/Shell (Unthreaded)	Signal	3 A	Copper Alloy	Polyester Glass Filled	-55 C	125 °C
