ZX60 Series

Catalog

IC RF AMP GPS 500MHZ-5GHZ

Part	P1dB	Test Frequency	RF Type	Package / Case	Voltage - Supply [Min]	Voltage - Supply [Max]	Noise Figure	Gain	Current - Supply	Frequency [Min]	Frequency [Max]	Mounting Type	Voltage - Supply	Test Frequency [Min]	Test Frequency [Max]
Mini-Circuits ZX60-53LN+	19.5 dBm	4 GHz	General Purpose	Module SMA Connectors	4.9 V	7 V	1.9 dB	23.9 dB	80 mA	500 MHz	5 GHz	Chassis Mount
Mini-Circuits ZX60-14012L-S+	11 dBm		General Purpose	Module SMA Connectors			5.5 dB	12 dBi	62 mA	300 kHz	14 GHz	Chassis Mount	12 VDC	300 kHz	14 GHz
Mini-Circuits ZX60-06183LN+	12 dBm		Radar	Module SMA Connectors	4.9 V	7 V	2 dB	25.2 dBi	64 mA	6 GHz	18 GHz	Chassis Mount		8 GHz	12 GHz
Mini-Circuits ZX60-24A-S+	19.4 dBm	18 GHz	DBS Radar	Module SMA Connectors			7.2 dBm	24.4 dB	270 mA			Chassis Mount
Mini-Circuits ZX60-153LN-S+	16.5 dB	2 GHz	LTE Radar UMTS WiFi WiMAX WLAN	Module SMA Connectors			3.6 dB	14.9 dB	82 mA			Chassis Mount	12 VDC
Mini-Circuits ZX60-3018G-S+	12.8 dBm	20 MHz	Cellular PCS	Module SMA Connectors			2.7 dB	18.8 dB	34 mA	20 MHz	3 GHz	Chassis Mount
Mini-Circuits ZX60-V62+	19.7 dBm	50 MHz	CATV DBS LTE Radar SATCOM Wireless LAN	Module SMA Connectors	4.8 V	5.2 V		14.4 dBd	82 mA	50 MHz	6 GHz	Chassis Mount
Mini-Circuits ZX60-2531MA-S+	19 dBm	500 MHz	Cellular PCN	Module SMA Connectors	2.8 V	5 V	3.1 dB	37 dB	102 mA	500 MHz	2.5 GHz	Chassis Mount
Mini-Circuits ZX60-83LN12+	20.7 dBm	2 GHz	LTE Radar WiFi WiMAX WLAN	Module SMA Connectors	11 VDC	13 V	2.3 dB	18 dBi	77 mA	500 MHz	8 GHz	Chassis Mount
Mini-Circuits ZX60-100VH+	30 dBm		General Purpose	Module SMA Connectors			4 dB	36 dBi	320 mA	300 kHz	100 MHz	Chassis Mount	12 VDC	300 kHz	100 MHz
